Key Features
5-Ton Lifting Capacity: Engineered to lift heavy loads up to 5,000kg, making it suitable for SUVs, light trucks, and heavy machinery.
Durable Hydraulic System: Features a high-quality hydraulic pump and piston assembly for smooth, controlled lifting and lowering.
Adjustable Screw Top: Equipped with a heat-treated extension screw on the saddle that allows for easy height adjustment and maximum lift range.
Rugged Steel Construction: Built with a heavy-duty steel frame and a wide, stable base to ensure safety and prevent tipping during use.
Safety Overload Protection: Includes an integrated safety valve to prevent the jack from being used beyond its rated capacity.
Compact & Portable Design: Its small footprint makes it easy to store in a vehicle trunk or workshop cabinet for emergency roadside repairs.
Specifications
Lifting Capacity: 5 Tons (5,000kg).
Minimum Height: 197mm (The height of the jack when fully retracted).
Maximum Height: 382mm (The total reachable height with the screw extended).
Hydraulic Stroke: 125mm (The distance the piston travels via hydraulic pumping).
Adjustable Screw Extension: 60mm (Additional height provided by the heat-treated saddle screw).
